Inteli-Lift 125/250

The Inteli-Lift Dumbwaiter from Elevation Innovation incorporates technology for ease of installation, usage, and maintenance. The controller has a solid state relay logic design and is capable of up to six floors with a front and rear door. The standard system has stainless steel tamper resistant Halo buttons an in use light as well as a car here indicator and arrival buzzer if required.

Request A Quote

Features

  • Intelligent Commercial Dumbwaiter controller with LED indicators
  • VFD variable frequency drive gives complete motor control and protection
  • Soft start and soft stop
  • Call / sends with momentary push button controls
  • In use LED with car here indicators
  • Arrival buzzer is optional and standard on all food service systems
  • Stainless steel or Mild steel one piece cab Custom aluminum rail system
  • 125 Lb. & 250 Lb. residential dumbwaiter cabs available in 3/4″ Russian Birch
  • Maintenance free 3 phase Bauer motor/gear assembly made in Germany
  • Safety devices: slack cable, final top / lower limit and a type A safety brake
  • Interlock door safety devices UL Certified
  • 125 or 250 Lb capacity (Fully UL Certified)
  • 30 fpm rated commercial dumbwaiter speed (50 fpm available)
  • Economical, reliable cable drive
  • Travel up to 75 feet and 9 stops
  • 115V or 230V Commercial Dumbwaiter operation 1 phase or 3 phase 50/60 Hz.
  • Roll up or bi-parting gate systems
  • 50 Db motor sound rating – same as a refrigerator only in an enclosed shaft
  • Additional car here LED for food service – position anywhere to alert servers
  • Select-able do not interrupt timer, select from 0 – 80 seconds

Options

  • Pre-Hung swing dumb waiter doors 90 minute rated stainless steel
  • Bi-parting or slide up 90 minute rated stainless or mild steel dumb waiter doors
  • Cab configurations including same side and front/back and 90*
  • 230 Volt 50/60 Hz dumb waiter operation
  • 24 Volt LED car light remotely located to alert staff
  • Remote 24V car here device of choice
  • Electrical disconnect

Warranty

Any new dumbwaiter sold and installed by Maine Accessibility comes with a 1-year labor warranty. If you have ANY problems with your dumbwaiter in the first year, we will come fix it free of charge.

Elevation Innovation also includes a 3 year limited warranty.
