Elevation Innovation Econo-Lift
Elevation Innovation Econo-Lift
Elevation Innovation Econo-Lift

Elevation Innovation Econo-Lift®

The Econo-Lift® Dumbwaiter from Elevation Innovation incorporates technology for ease of installation, usage, and maintenance. The system includes a UL certified solid state relay logic controller. The electrical components are all pre-wired for ease of installation. Quick connectors are used to tie the included EMI interlocks and level limit switch to the pre-wired call/send stations. An in use indicator is included on each call/send station. Available car here light with upgrade.


  • ETL certified to ASME A17.1 and CSA C22.2 #B44 codes for the USA & Canada
  • Operates under 36" kitchen cabinet
  • Finished 9 ply birch cab with dovetailed joints / Powder coat or stainless steel
  • Roll up Silver line gate system
  • Cab configurations including front/back and 90 degree, three sides available
  • VFD (variable frequency drive) Relay logic dumbwaiter controller
  • Commercial grade aluminum rail / trolley system
  • Safety devices including slack cable, final limits, and trolley brake
  • Honeywell EMI interlock door safety devices
  • 100 lb or 150 lb capacity included
  • 30 fpm rated speed
  • Economical, reliable, simple to install cable drive
  • Maintenance free 3 phase motor / gear assembly
  • 115V 15 amp dumbwaiter operation
  • Travel up to 45 feet and 4 stops
  • Upper and lower emergency physical stops
  • Call / Send stations with in use LED light
  • Standard black or upgraded call / send buttons
  • Warranty - 5 year Limited Parts


  • Deflection: 100 lb. and 150 lb. dumbwaiter meet all codes per ANSI for cab deflection
  • Design: Floor loading or Counter height
  • Car Size: 20” x 20”x 30” (100 lb.) or 24” x 24” x 30” (150 lb.) Custom Size and Shape, up to 10 ft cubed
  • Material: 9 Ply Birch with two coats of clear finish 12 Ply Optional, Powder coated steel or Stainless
  • Opening: One or two or three sides available
  • Capacity: 100 or 150 lbs
  • Speed: 30 fpm
  • Power: 115v (standard), 200v / 230V 50Hz operation available
  • Power Unit: Floor mount, Wall mount motor above or below
  • Winding Drum: High torque electric motor and completely enclosed worm gear, drums machined to accommodate a single 1/8” 7 x 19 ANSI IPS galvanized steel cable.
  • Guide Rail: Monorail type
  • Controls: Fully automatic allowing car to be sent or called from any floor. Terminal limit switch provided for finals. Car stops automatically at landing levels. Door interlocks for hoist-way doors to prevent operation of the dumbwaiter unless doors are closed and to prevent opening of any door except when the car is at the landing.
  • Optional Equipment: Removable adjustable shelves. Key lock out options (shut down controller or any call/send station). Fire rated hoist-way doors 20 minute rated and 90 minute rated. Stainless steel push buttons with halo LED car here light


Any new dumbwaiter sold and installed by Maine Accessibility comes with a 1-year labor warranty. If you have ANY problems with your dumbwaiter in the first year, we will come fix it free of charge.

Elevation Innovation also includes a 5 year limited warranty.
