Luxury Lift LLH – Variable Speed Traction Residential Elevator
Luxury Lift LLH – Variable Speed Traction Residential Elevator
Luxury Lift LLH – Variable Speed Traction Residential Elevator

Residential Elevators Luxury Lift Hydraulic

The Luxury Lift LLH residential elevators are built using the same design criteria developed over decades and used in the commercial and industrial elevator market. Residential Elevators's Luxury Lift LLH gives the lifting capacity normally available only with commercial elevators. Complement the Luxury Lift LLH with your personal choice of cab appointments and enjoy commercial elevator features at residential elevator prices.

Low maintenance consistent with Residential Elevators's reputation and demonstrated track record for reliable and highly engineered hydraulic elevators.

Features

  • 950 lb. capacity
  • Auto Lowering Emergency System
  • Travel standard up to 50 ft.
  • Travel speed of 40 ft. per minute
  • Two-speed leveling valve
  • Cab Height 6'-8"
  • 3/8" Heavy Duty Aircraft cables
  • PLC (Programmable Logic Controls) Controller
  • 3/4" sturdy cab walls (7 ply custom cabinet grade material)
  • Custom made cab and interior to your specifications
  • Aluminum anodized scissor gate or accordion style solid gate
  • Standard interior cab color
  • Single LED light
  • Solid matching hardwood handrail
  • Single integrated car operating panel with built-in phone and emergency light
  • "Car Here" and "In Use" indicators Meets or exceeds all ASME/ANSI A17.1 National Safety Codes for Elevators – Section 5.3 Private Residence Elevators.

Options

  • Woods other than standard
  • Additional gate(s)
  • Custom gate(s)
  • Overheight cab up to 8′-0″
  • Variety of custom cabs
  • Observation glass panel inserts
  • 750 lb. capacity (as necessary by code in certain areas)
  • Mirror with hardwood trim
  • Keyed hall station
  • Multiple LED lights
  • Attic mount installation
  • Auto homing / auto light / autorun

Warranty

Any new elevator sold and installed by Maine Accessibility comes with a 1-year labor warranty. If you have ANY problems with your lift in the first year, we will come fix it free of charge.
